- 7.45" (189mm) x 5.85" (149mm) x 2.1" (52mm)

- Size: 3.2"
- Type: FSTN Monochrome
- Pixels: 128 x 64
- Numeric Keypad, System Keys, Soft Keys
- 8 Relegendable Function Keys
- Three front panel LED indicators

  +24 VDC ±20%

- Up to 5 RS-232/422/485
  2 RS-232 and 1 RS-422/485 on board
  1 RS-232 and 1 RS422/485 on Option Card

- 10 Base T/100 Base-TX Ethernet Port
  Supports multiple protocols simultaneously

- USB 1.1 port (type B)
  Download the unit’s configuration from a PC
  Data Transfers to a PC

- Multiple protocol converter

- DeviceNet, CANopen and Profibus DP option cards

- 8 Mbyte Flash
  Unit’s configuration is stored in Non-volatile memory

- Extensive driver list
- Built-in Web Server and FTP Server/Client
   Remote Web Access and Control Facility
- CompactFlash Socket for Database/Recipe Storage and Data Logging
- Configured only using free Crimson 2.0 Software
- UL Listed for use in Hazardous Locations.
  (See literature for class and division details.)

- NEMA 4X / IP66
