Home > Instrumentation > HMI Display Panels > Paradigm HMI
Red Lion Paradigm HMI
Red Lion Controls


TX700T00


    Red Lion Controls - USA
     TX700T 10" TFT Color Graphical Touch Panel HMI
     Paradigm HMI display
    Size

    - 12.2" (310mm) x 8.64" (220mm) x 2.52" (64mm)

    Display

    - 640 x 480 pixels (10.4")
      CCFL Liquid Crystal TFT color full VGA display.
      Text formats up to 40 x 30 characters.
    - 6 screen soft keys with slide out softkey menus
    - System keys
    - 200 x 200 Cell Resistive Touchscreen

    Supply voltage

      15-30Vdc

    Communications

    - One RS232 and one RS485
    - One RS232 programming port
      Check data sheet for communication modes

    Memory

    - 736 K (672 K user) battery backed RAM

     Other features

    - 500 Alarm Point Scanner
    - Recipe Handling
    - 32-bit and floating point math
    - Direct, Network or Modem PLC Control
    - Configured using EDICT 97

    Protection

    - NEMA 4 / IP65










Red Lion TX700T00 HMI

Red Lion Controls
