Red Lion DSPGT001 protocol converter, VGA virtual HMI (ext. temperature)
Part: DSPGT001
-
Product Information
-
The DSP Data Station Plus product family has been marked as "End of Life" by Red Lion Controls. Please contact us to check if the part you require is still available to order.
DSP Data Station Plus alternatives.
Red Lion enhances the Data Station Plus product range by adding an extended operating temperature model that supports installation in non-climate controlled environments. The Data Station Plus now features an expanded operating temperature of -20° to 70°C, which allows for mounting in non-temperature controlled environments such as outdoor enclosures or warehouses.
Additionally, the Data Station Plus can now be installed closer to the equipment being monitored, which means quicker and easier deployments with fewer cable runs.
Manufacturer: Red Lion - USA Part: DSPGT001 Function: Protocol converter with web server, data logging, FTP server and synchronization for file transfer, OPC Server. Extended temperature range. Virtual HMI: VGA 640x480 provides remote monitoring and control Web server: Enables remote access to virtual HMI pages, data log files, custom data pages and custom web pages. Serial data ports: RS232 x 2, RS485/RS422 x1 serial communications. Ethernet port: 10/100 Base-T x1 supports multiple protocols. USB port: USB specification 1.1. Device only using Type B connection. For programming only. Memory Card: CompactFlash Type II slot for Type I and Type II cards. To increase memory for data-lofg files and custom web pages. Power supply: 24VDC Operating Temperature Range: -20 to 70C Expansion: Optional expansion cards can be installed in the front
-
-
